16 port 100Mbps switch with 2G combo

In stock
£306.00 £255.00
16 PoE ports, 10/100 mbps each port 2 Gigabit Uplink ports for high speed connection 2 Gigabit fiber optic ports for high speed connection Base on web management, easy and convenient
Gigabit fiber optic ports, 16 PoE ports.
Key feature:
16 PoE ports, 10/100 mbps each port
2 Gigabit Uplink ports for high speed connection
2 Gigabit fiber optic ports for high speed connection
Base on web management, easy and convenient
16 PoE ports solutions and web-smart management
PS1016S fill the gap of non-webmanagement and full-webmanagement switch. PS1016S design for developing enterprise, it can control the website but the price is much better than full webmanagement switch and easy operate.As for PoE switch, it supply power and transfer data with 802.3af standard.It also offer web management tool which make the AP, VoIP telephone and IP camera work in the good condition.
There are many superior features, like visit ACL, 802.1x port certification,stronger QoS, port speed limit and IGMP monitoring,enterprise website will get much more progress with these features. 2 Gigabit Uplink ports and 2 Gigabit fiber optic ports are very advantageous for dveloping enterprise ,classroom and some other users, it follow up the development of website.This series smart switch has 11.2Gbps brandwidth, all ports are RJ-45 port and it can reach the highest speed and support Auto Uplink technology, all of these can make sure correct connection.
PoE function
The total output is 250W, supply power for 16 Ethernet devices or 16 IP devices with 802.3af standard.It’s more convenient for the installing of AP,VoIP and IP camera and power source management by PoE. PoE save the installing time and cost for many users.You can make your AP and IP cameras get freedom from many wires just by a standard CAT-5 wire.All PoE devices can get power from UPS.
Advanced security
802.1x for identification
ACL allow or prevent visiting base on MAC address
Product name
16-port multi-functional intelligent network switch
Order No.
Network protocols and standards
- IEEE 802.3 10BASE-T
- IEEE 802.3u 100BASE-TX
- IEEE 802.3ab 1000BASE-T
- IEEE 802.3z 1000BASE-X
- IEEE 802.3x Flow Control
- IEEE 802.3af Power over Ethernet
Power Specifications
- Power consumption: maximum 270W
- PoE Power: 250W
- Voltage: 100 - 240 VAC, 50 -60 Hz
Network interface
- 16 10/100M ports (MDI / MDIX adaptive); ports with PoE features (24)
- 2 10/100/1000M Gigabit copper RJ45 ports (MDI / MDIX adaptive)
- 2 SFP GBIC fiber module slots
Physical Specifications
- Dimensions: 440 x 350x 43 mm
- Weight: 5.5 kg
Electromagnetic radiation
- CE mark, commercial
- FCC Part 15 Class A
- VCCI Class A
- C-Tick
Environmental norms
- Operating Temperature: 0 ° - 50 ° C
- Storage Temperature: -20 ° - 70 ° C- Operating Humidity: Maximum relative humidity 90% without condensation
- Storage humidity: 95% maximum relative humidity, non-condensing
- Working height: up to 10,000 feet (3,000 meters)
- storage altitude: the largest 10,000 feet (3,000 meters)
- Each device: power light
- Each device: WEB indicator
- Per port (10/100 and Gigabit): connection
speed indicator
- Per PoE port: PoE power-on LED
Radiation / electromagnetic immunity,
- EN 55024
- CE mark, commercial
- cUL 60950 (Listed) / EN60950
Performance Specifications
- Forwarding modes: Store and forward
- Bandwidth: 7.2Gbps (non-blocking)
- network latency: 100 Mbps to 100 Mbps transmission, storage and forwarding mode under a 64-byte frame delay is less than 20 microseconds
- Buffer memory: 3Mb per system
- Addressing: 48-bit MAC address
- the address database size: 8,000 per system MAC address
- Mean failure interval (MTBF): 300,000 hours (about 34 years)
1 year
Package Contents
- PS1016  16-port multi
- functional intelligent network line-powered switch rubber feet
- the power cord - rack kit
- Installation guide
- Warranty / support information card
