Standard
|
IEEE802.3 10BASE-T-Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE802.3at+ POE Power over Ethernet standard
|
|
Agreement
|
CSMA/CD Ethernet
|
|
Data transfer rate
|
Ethernet: 100Mbps (half duplex) 200Mbps (full
Duplex) Fast Ethernet: 1000Mbps (half duplex)
2000Mbps (full duplex)
|
|
Physical media
|
100BASE-T
|
|
3, 4 and 5 unshielded twisted pair cable (maximum length 10m)
|
|
|
The EIA/TIA-568 100-ohm shielded twisted pair cable (the maximum
Length of 100m)
|
|
|
1000BASE-TX
|
|
|
Cat5 unshielded twisted pair cable (maximum length 100M)
|
|
|
The EIA/TIA-568 100-ohm shielded twisted pair cable (the maximum
Length of 100m)
|
|
|
The number of ports
|
16 ( upward 8 ports are POE port, downward 8 ports are data output port)
|
|
Supply power way
|
1 2 3 6 and 4 5 7 8
|
|
Switch
|
On/Off power switch
|
|
LED indicator
|
Power indicator, fault indicator, the PSE power supply instructions
Light
|
|
Physical environment
|
|
|
Power input
|
AC100-240V ～50-60HZ
|
|
Source power consumption
|
No load 2.8W (MAX): full load: 240W
|
|
Operating temperature
|
-10～50℃
|
|
Storage Temperature
|
-40～70℃
|
|
Humidity
|
5% ~ 95% non-condensing
|
|
Size
|
270*180*45mm (1U Rack)
|
|
Gross Weight
|
3kg
|
